BTC-1648
The BTC-1648 was a high-end 64-bit PCI graphics card compatible with the VGA standard.
|
Released | 1997 |
| Bus | PCI 2.0 | |
| Chipset | ARK Logic Quadro64 (ARK2000MI Plus) | |
| Standards | Hercules, CGA, EGA, VGA | |
| Memory | 2 MB EDO DRAM | |
| Ports | 15-pin DSUB (video out) 26-pin VGA Feature connector |
|
| RAMDAC | (Integrated) | |
| Part # | ||
| FCC ID | ||
| Price | ||
| See Also |
The BTC 1648 VGA card used the ARK Logic Quadro64 graphics and video accelerator chipset. It had a 32-bit PCI interface, 64-bit wide path to memory, and graphics coprocessor that took the strain off the main CPU in Windows.
The supported display resolutions for the BTC 1648 range from 1600x1200 in 256 colors (at a 75 Hz refresh rate) to 800x600 in 16.7 million colors (at a 90 Hz refresh rate).
Board Revisions
Competition
In the Media
Setting it Up
I have no configuration information for these cards.
Downloads
Operation Manual Get in touch if you can provide this missing item! |
Original Driver Disk Get in touch if you can provide this missing item! |
|
More Pictures
